3-in-1 Ophthalmic Ultrasound - A/B Scans and Pachymetry

Together with its high quality B-scan mode, and the optional biometry and pachymetry modules, Compact Touch™ sets the standard in portability for ophthalmic ultrasound systems


The new Compact Touch™ combines the A/B-Scan system and optional pachymetry mode with a new generation of 15MHz probe with a resolution increased by 30% that redefines the gold standard in B-mode imaging by bringing an exceptional image quality for a better and quicker diagnosis. This 3-in-1 system combines outstanding image and measurement performance with exceptional ergonomics and intuitiveness. The compact design and lack of an external PC make it easy to transport between offices. At the same time, the connectivity lets you easily interface its data to your DICOM, EMR, or Wifi network.

  • A new 15 MHz B-mode imaging that produces exceptional image quality, for a better and quicker diagnosis
  • Precision in A-Scan and IOL calculation
  • Easy glaucoma screening with the pachymetry option
  • Mobile versatility

Redefining the Standard in B-Scan Imaging

A new 15 MHz B probe with a resolution increased by 30% allows for better visualization of the eye structures and the orbit hence a better diagnosis.

  • High Frame Rate Functionality - Provides real-time imaging when a kinetic examination is crucial
  • Biometry in B-mode - Exclusive to the compact touch, it allows to automatically measure the axial length from a B-mode image
  • Small in Size - This probe benefits from an excellent ergonomics to facilitate its handling and use



Precision in A-Scan and IOL Calculation

The patented A-scan Probeam™ technology is exclusively from Quantel Medical. This probe generates a laser beam that offers a fixation point to the patient facilitating: this facilitates the measurement while increasing the ease of acquisition.

The IOL calculation function allows comparison between different IOL types and calculation formulas.  A total of 12 IOL calculation formulae are available including post-refractive surgery formulae.


Easy Glaucoma Screening with the Pachymetry Option

Essential for glaucoma diagnosis and refractive surgery, Compact Touch offers several measuring modes and corneal maps with an accuracy of ± 5 microns.

Built-in IOP correction calculation tables provide the ability to adjust for variations in intraocular pressure.

For refractive surgery, several measuring modes and corneal maps are available.

A Sleek Design, with Increased Ergonomics

The new design now weighs less than 4kg, and its dimensions have been significantly reduced to fit better in every working environment.

Thanks to its foldable and reclining carrying handle, it is more easily transportable.

To further increase working ergonomics around the patient, its VESA fixation system offers the possibility to be mounted either on a wall, on an articulated arm, or on a mobile trolley.

B Probe 15 MHz - General Diagnosis Probe

Automatic biometry readings obtained from a B mode image allow axial length measurements for difficult-to-measure long eyes or posterior staphyloma.



Biometry Probe

Biometry probe for axial length measurement with built-in pattern recognition, automatic calculation of standard deviation and average total length.

Biometry Probe with ProBeam Laser Pointer

Biometry probe with an integrated laser to ensuring the acquisition in the visual axis, increasing the patient cooperation and accelerating the speed of acquisition of A scans.

Pachymetry Probe

Pachymerty probe allows for a quick and reliable measurement of the central corneal thickness thanks to its 20 MHz probe.
